Biggest Differences Between Passenger Vehicle TPMS & Commercial Vehicle TPMS

A question we’re often asked is can a passenger vehicle TPMS be used on commercial vehicles such as trucks and construction equipment?

The answer is sometimes. The basic purpose of both systems are the same - monitoring tyre pressure and temperature to help improve safety, tyre life and save time. However, commercial vehicles typically have very different requirements to cars, 4WDs and caravans.

Trucks and heavy vehicles can have significantly more tyres, higher tyre pressures and longer operating hours. Certain trucks may also have multiple axles along with dual-wheel configurations. This makes it important for the TPMS to be able to monitor different vehicle combinations.

In this guide, we’ll explain the biggest differences between passenger vehicle and commercial vehicle TPMS and what to look for when choosing a system for trucks and heavy-duty applications.

1) Pressure Monitoring Range

One of the most important differences between passenger vehicle and commercial vehicle TPMS is the maximum tyre pressure the system can monitor.

• Passenger Vehicle TPMS: Most systems designed for cars, 4WDs, caravans and trailers typically monitor pressures from 0-99 PSI. This range is more than sufficient for most passenger vehicles and recreational applications.
• Commercial Vehicle TPMS: Trucks and other heavy-duty vehicles can require significantly higher tyre pressures, particularly when carrying heavy loads. Commercial TPMS are therefore often designed with a much higher pressure range in mind - monitoring up to 200 PSI.

2) Number of Tyres and Sensors

Another major difference between passenger vehicle and commercial vehicle TPMS is the number of tyres the system needs to monitor.

• Passenger Vehicle TPMS: Most systems designed for cars, 4WDs, caravans and light trailers monitor a relatively small number of tyres - usually up to 10 tyres or fewer. For example, a system might monitor four tyres on the towing vehicle, four on a caravan or trailer, plus one or two spare tyres.
• Commercial Vehicle TPMS: Trucks and heavy vehicles can have dozens of tyres, particularly when multiple trailers, dollies or other equipment are involved.

This makes the number of sensors a critical consideration when choosing TPMS. A system designed for a passenger vehicle may simply not have enough capacity to monitor an entire truck and trailer combination.

3) Scale and Monitoring Range

Even with a signal booster, the range on most passenger vehicles TPMS generally max out at around 20 meters. However, the distance between the driver’s display and the furthest tyre can be substantially greater on a truck or multi-trailer combination than on a passenger vehicle. Commercial vehicles can stretch indefinitely across several trailer combinations using repeater kits which relay and increase signal strength. They can also be designed to monitor multiple trailers simultaneously, making them suitable for combinations such as B-doubles or road trains. Finally, commercial TPMS can also offer features specifically designed for large vehicle combinations such as grouping sensors by axle or trailer.

4) Durability and Reliability

Commercial vehicles generally operate for much longer periods and in more demanding environments. As such, they feature larger or longer-lasting batteries to handle more frequent transmission reading. A sensor with a larger battery or longer battery life can help reduce the frequency of battery replacements and minimise maintenance downtime. This is particularly important when a vehicle has dozens of sensors, as replacing batteries across an entire truck and trailer combination can become time-consuming. Although the stated lifespan for passenger vs commercial TPMS sensors may be the same (2 years for external and 5 years for internal), passenger vehicles rarely run for more than 2 hours a day. Commercial vehicles on the other hand can run 12 hours a day and 7 days a week.

Commercial TPMS sensors may need to withstand harsher conditions than those encountered by passenger vehicles. For this reason, commercial-grade systems may use more robust housings and higher levels of environmental protection to improve reliability in demanding applications.

5) Other Features Designed for Commercial Vehicles

Beyond specifications, TPMS often include additional features designed to make monitoring large and complex vehicle combinations easier.

• Larger Displays: When monitoring dozens of tyres, displaying all the information clearly becomes important. Truck and heavy vehicles TPMS often use larger displays or layouts. This makes it easier to identify which tyre requires attention.
• Wireless Pairing: The ability to wireless pair sensors can significantly simplify sensor replacement, particularly when a vehicle has a large number of tyres.
• Drop Hook Functionality: This is especially important for trucks towing trailers or dollies. Drop Hook enables the TPMS to automatically recognise the sensors on a trailer or dolly wheels as soon as they’re attached. This saves time by reducing the hassle of manually connecting/disconnecting the sensors every time a trailer is attached or detached.
